杰昊雾淋室
生产高活性药物成分（API）的制药和精细化工行业的工作人员在使用这些具有药理活性的粉末时通常会穿防护服，工作人员在接触粉末的过程中，会有细微粉尘粘附于工作服上，在从受控区到非受控区脱卸工作服时，会将粉尘散落至空间中造成污染或呼吸至体内造成人身危害，为降低这些材料从受控区域到非受控区域形成污染及造成对工作人员的人身危害，需要进入雾淋室将有害物质去除。它被设计于在退出区域时的脱衣过程中提供保护。雾化淋浴已经经过独立测试和验证，证明雾化过程能有效包裹操作人员的服装,雾化淋浴产生的废水量很少，便于处理。
技术规格：
- 材料：不锈钢304箱体，坚固、光滑、易于清洁
- 标准尺寸：1200mm x 1200mm x 2400mm，可根据客户要求定制其它尺寸
- 门：带有观察窗的不锈钢304密封门，具有互锁功能
- 喷嘴：定制不锈钢喷嘴，由压缩空气驱动喷雾
- 照明：防水LED照明
- 控制面板：带互锁功能的西门子PLC界面面板
- 门控：每个门配有按钮和电磁锁
- 紧急退出：设备内部安装有急停按钮，可原路退出
- 气阀：用于进气和排气的电磁阀
- 管道：用于进气和排气的不锈钢管
- 排水：每个舱室的地板排水
- 电源：AC220V，50HZ
选项
- 箱体材料升级：可选不锈钢316L箱体
- 门的密封性升级：可选充气密封门
- 生命支持系统：可选安装生命支持系统
Jiehao Mist Shower
In the pharmaceutical and fine chemical industries that produce high-potency active pharmaceutical ingredients (APIs), workers typically wear protective clothing when handling these pharmacologically active powders. During the process, fine dust particles may adhere to the work clothes. When workers remove their work clothes from controlled to uncontrolled areas, the dust may scatter into the space, causing environmental pollution or being inhaled into the body, posing a threat to personal health. To reduce the risk of contamination from controlled areas to uncontrolled areas and to minimize potential harm to workers, it is necessary to enter the mist chamber to remove harmful substances. The mist chamber is designed to provide protection during the clothing removal process when exiting the area. The mist shower has been independently tested and verified to effectively encapsulate the operator's clothing, and it produces a minimal amount of wastewater that is easy to handle.
Technical Specifications
- Materials: Stainless steel 304 chamber, robust, smooth, and easy to clean
- Standard Size： 1200mm x 1200mm x 2400mm, with customization options based on client requirements
- Doors: Sealed doors made of stainless steel 304 with observation windows and interlocking functionality
- Nozzles: Customized stainless steel nozzles driven by compressed air for mist spraying
- Lighting: Waterproof LED lighting
- Control Panel: Siemens PLC interface panel with interlocking function
- Access Control: Buttons and electromagnetic locks for each door
- Emergency Exit: An emergency stop button installed inside the equipment for immediate exit
- Valves: Electromagnetic valves for air intake and exhaust
- Pipes: Stainless steel pipes for air intake and exhaust
-*Drainage: Floor drains for each cabin
- Power Supply: AC220V, 50HZ
Options
- Chamber Material Upgrade: Optional stainless steel 316L chamber
- Door Sealing Upgrade: Optional inflatable seal doors
- Life Support System： Optional installation of a life support system
